Robots help to answer age-old question of why fish school

Study using biomimetic fish-like robots shows that swimming closely together offers fish hydrodynamic benefits—providing first experimental validation of an answer to an old question

A fish school is a striking demonstration of synchronicity. Yet centuries of study have left a basic question unanswered: do fish save energy by swimming in schools? Now, scientists from the Max Planck Institute of Animal Behavior (MPI-AB), the University of Konstanz, Peking University and Eötvös Lóránd University have provided an answer that has long been suspected but never conclusively supported by experiments: yes.

Using biomimetic fish-like robots, the researchers show that fish could take advantage of the swirls of water generated by those in front by applying a simple behavioural rule. By adjusting their tail beat relative to near neighbours—a strategy called vortex phase matching—robots were shown to benefit hydrodynamically from a near neighbour no matter where they are positioned with respect to that neighbour. The previously unknown rule, revealed by the robots, was subsequently shown to be the strategy used by free swimming fish. The study is reported on 26 October in Nature Communications.

“Fish schools are highly dynamic, social systems,” says senior author Iain Couzin, Director of the MPIAB who also co-directs the Cluster of Excellence ‘Centre for the Advanced Study of Collective Behaviour’ at the University of Konstanz. “Our results provide an explanation for how fish can profit from the vortices generated by near neighbours without having to keep fixed distances from each other.”

Robotic solution

Answering the question of whether or not fish can save energy by swimming with others requires measuring their energy expenditure. Accurately doing so in free swimming fish has so far not been possible, and so past studies have sought to answer this question instead through theoretical models and predictions.

The new study, however, has overcome this barrier to experimental testing. The researchers developed a 3D robotic fish that has a soft tail fin and swims with an undulating motion that mimics accurately the movement of a real fish. But unlike their live counterparts, the robots allow for direct measurement of the power consumption associated with swimming together versus alone.

“We developed a biomimetic robot to solve the fundamental problem of finding out exactly how much energy is used in swimming,” says Liang Li, a postdoctoral fellow at the MPI-AB and first author on the study. “If we then have multiple robots interacting, we gain an efficient way to ask how different strategies of swimming together impact the costs of locomotion.”

A simple rule for swimming in a school

The researchers studied robotic fish swimming in pairs versus alone. Running over 10,000 trials, they tested follower fish in every possible position relative to leaders—and then compared energy use with solo swimming.

The results showed a clear difference in energy consumption for robots that swam alone versus those that swam in pairs. The cause of this, they discovered, is the way that fish in front influence the hydrodynamics of fish behind. The energy consumed by a follower fish is determined by two factors: distance behind the leader and the timing of tail beats.

To save energy, it turns out that the secret is in synchronisation. That is, follower fish must match their tail beat to that of the leader with a specific time lag based on the spatial position—a strategy the researchers called “vortex phase matching.” When followers are beside leader fish, the most energetically effective thing to do is to synchronise tail beats with the leader. But as followers fall behind, they should go out of synch having more and more lag as compared to the tail beat of the leader.

Visualising vortices

In order to visualise the hydrodynamics, researchers emitted tiny hydrogen bubbles into the water and imaged them with a laser—a technique that made the vortices created by the swimming motion of the robots visible. This showed that vortices are shed by the leader fish and move downstream. It also showed that robots could utilise these vortices in various ways. “It’s not just about saving energy. By changing the way they synchronise, followers can also use the vortices shed by other fish to generate thrust and help them accelerate,” says co-author Mate Nagy, head of the Collective Behaviour 'Lendület' Research Group in the Hungarian Academy of Sciences and Eötvös University, who conducted the work mostly when he was a postdoctoral fellow at the MPI-AB.

The result in real fish

But do real fish use the strategy of vortex phase matching to save energy? To answer that, the researchers created a simple hydrodynamic model that predicts what real fish should do if they are using vortex phase matching. They used AI-assisted analysis of body posture of goldfish swimming together and found, indeed, that the strategy is being used in nature.

Says Couzin: “We discovered a simple rule for synchronising with neighbours that allows followers to continuously exploit socially-generated vortices. But before our robotic experiments, we simply didn’t know what to look for, and so this rule has been hidden in plain sight.”

Li, L., Nagy, M., Graving, J. M., Bak-Coleman, J., Xie, G., & Couzin, I. D. (2020). Vortex phase matching as a strategy for schooling in robots and in fish. Nature Communications, 11(1), 1-9.
